Disposable plastic straw pipe/dropper is widely used in laboratory, food research, medical industrial etc. Specifications are 0.2ml、0.5ml、1ml、2ml、3ml、5ml、10ml Etc
Model | Unit | BM02D |
Max product volume | L | 2 |
Dry cycle | Pc/h | 900*2 |
Die head structure | Continuous type | |
Main screw diameter | mm | 65 |
Max plasticizing capacity | Kg/h | 70 |
Driving motor | Kw | 22 |
Oil pump motor power(Servo) | L | 11 |
Clamping Force | KW | 40 |
Space between platen | KN | 138-368 |
Platen size W*H | mm | 286*330 |
Max.mould size | mm | 300*350 |
Platen moving stroke | mm | 420 |
Heating power of die head | KW | 6 |
Machine dimension L*W*H | m | 3.0*1.9*2.4 |
Machine weight | T | 5 |
Total power | KW | 45 |
Long opening stroke and linear movements
Single and double station
Hydraulic, hybrid, or all electric platforms available
Less energy consumption and more clamping force.
Trimming and leak test online
Servo robot take-out
Optional view stripe and co-extrusion
AC inverter extruder drive controllers
Single and multi-parison dieheads
JWZ-BMYL Medical Series Blow Molding Machine, designed to meet all your needs for producing disposable plastic straws/droppers of various specifications. With its continuous mold head and high-efficiency extrusion, this machine ensures seamless production. Our Machine also offers customization options, providing you with a complete solution tailored to your specific requirements. Trust in our professional-grade equipment to deliver exceptional results every time.
