Product Advantage
1、The pre-metered system of fluid reduce the waste and make sure the uniform thickness on the direction of the width,reduce the volatilization and make the operate environment more clean.
2、The pre-metered system of fluid reduce the waste and make sure the uniform thickness coating on the base materials and allowed the pump synchronous with the production speed.
3、The precise slot coating die producing decided the uniform of the coating thickness.
4、Allow the quick setup.
5、Shorten the time between the beginning of the coating and manufacture the satisfactory products. So it improve the production rate and reduce the waste.
6、Reduce the variable factor improve the stability when producing and repeatability.
7、Suitable for wide range different kind of coating fluid,base materials,coating width and coating thickness.
Technical Parameters
Max size :3000mm
Straightness accuracy : ≤2um/m
Coating layer thickness range : 1um to 250um (By replace shims)
Coating layer thickness tolerance: +5%
Die lip flow runner surface polish to Ra0.012um,other flow runner surface polish to Ra0.04um
Lip treatment：For the special coating fluid,the slot die adopt high hardness alloy with the base metal combined together to have better abrasion performance.The important part of the alloy will be made the acute angle to make sure uniform edge cutting.
