100ml-3000ml different size of Milk bottle,soy sauce bottle,yellow wine bottle.200ml-5000ml different size of shampoo bottle,body wash bottle, detergent bottles and others Toiletries and different children's toys.
· Suitable for producing 100ml-3000ml different size of Milk bottle,soy sauce bottle,yellow wine bottle.200ml-5000ml different size of shampoo bottle,body wash bottle, detergent bottles and others Toiletries and different children's toys.
· Optional pearly lustre layer co-extrusion system.
· According to the product size.select different cavity of die head.
· According to the different material,optional JW-DB single station hydraulic screen-exchanger system.
· According to customer's requirement.optional auto-deflashing on line,scrap conveying on line,finished product conveying on line and others.
Long opening stroke and linear movements
Single and double station
Hydraulic, hybrid, or all electric platforms available
Less energy consumption and more clamping force.
Trimming and leak test online
Servo robot take-out
Optional view stripe and co-extrusion
AC inverter extruder drive controllers
Single and multi-parison dieheads
Model | Unit | BM02D | BM05D | BM12D | BM20D |
Max product volume | L | 2 | 5 | 12 | 20 |
Dry cycle | Pc/h | 900*2 | 700*2 | 600*2 | 600*2 |
Die head structure | Continuous type | ||||
Main screw diameter | mm | 65 | 75 | 90 | 90 |
Max plasticizing capacity(PE) | Kg/h | 70 | 90 | 160 | 160 |
Driving motor | Kw | 22 | 30 | 45 | 45 |
Oil pump motor power(Servo) | Kw | 11 | 15 | 18.5 | 18.5 |
Clamping force | KN | 40 | 70 | 120 | 160 |
Space between platen | mm | 138-368 | 150-510 | 240-640 | 280-680 |
Platen size W*H | mm | 286*330 | 420*390 | 520*490 | 500*520 |
Max mould size | mm | 300*350 | 420*400 | 540*500 | 560*520 |
Platen moving stroke | mm | 420 | 450/520 | 600/650 | 650 |
Heating power of die head | Kw | 6 | 7.5 | 10 | 12.5 |
Machine dimension L*W*H | m | 3.0*1.9*2.4 | 3.7*3.1*2.7 | 4.2*3.2*3.0 | 4.3*3.2*3.1 |
Machine weight | T | 5 | 8.5 | 12 | 14 |
Total power | Kw | 45 | 60 | 90 | 93 |
JWZ-BMJY Household Product Series Double Station Blow Molding Machine, designed to cater to a wide range of specifications for packaging containers of daily chemical products. From 200ml to 5000ml, our machine efficiently produces shampoo, shower gel, dishwashing liquid, and other personal care products.
With our extensive manufacturing experience, we guarantee top-notch quality and excellent performance. Our machine supports multi-die head co-extrusion, ensuring high productivity to meet the demands of our customers.
Not only do our products boast exquisite craftsmanship, but they also offer exceptional versatility.
100ml-3000ml different size of Milk bottle,soy sauce bottle,yellow wine bottle.200ml-5000ml different size of shampoo bottle,body wash bottle, detergent bottles and others Toiletries and different children's toys.
· Suitable for producing 100ml-3000ml different size of Milk bottle,soy sauce bottle,yellow wine bottle.200ml-5000ml different size of shampoo bottle,body wash bottle, detergent bottles and others Toiletries and different children's toys.
· Optional pearly lustre layer co-extrusion system.
· According to the product size.select different cavity of die head.
· According to the different material,optional JW-DB single station hydraulic screen-exchanger system.
· According to customer's requirement.optional auto-deflashing on line,scrap conveying on line,finished product conveying on line and others.
Long opening stroke and linear movements
Single and double station
Hydraulic, hybrid, or all electric platforms available
Less energy consumption and more clamping force.
Trimming and leak test online
Servo robot take-out
Optional view stripe and co-extrusion
AC inverter extruder drive controllers
Single and multi-parison dieheads
Model | Unit | BM02D | BM05D | BM12D | BM20D |
Max product volume | L | 2 | 5 | 12 | 20 |
Dry cycle | Pc/h | 900*2 | 700*2 | 600*2 | 600*2 |
Die head structure | Continuous type | ||||
Main screw diameter | mm | 65 | 75 | 90 | 90 |
Max plasticizing capacity(PE) | Kg/h | 70 | 90 | 160 | 160 |
Driving motor | Kw | 22 | 30 | 45 | 45 |
Oil pump motor power(Servo) | Kw | 11 | 15 | 18.5 | 18.5 |
Clamping force | KN | 40 | 70 | 120 | 160 |
Space between platen | mm | 138-368 | 150-510 | 240-640 | 280-680 |
Platen size W*H | mm | 286*330 | 420*390 | 520*490 | 500*520 |
Max mould size | mm | 300*350 | 420*400 | 540*500 | 560*520 |
Platen moving stroke | mm | 420 | 450/520 | 600/650 | 650 |
Heating power of die head | Kw | 6 | 7.5 | 10 | 12.5 |
Machine dimension L*W*H | m | 3.0*1.9*2.4 | 3.7*3.1*2.7 | 4.2*3.2*3.0 | 4.3*3.2*3.1 |
Machine weight | T | 5 | 8.5 | 12 | 14 |
Total power | Kw | 45 | 60 | 90 | 93 |
JWZ-BMJY Household Product Series Double Station Blow Molding Machine, designed to cater to a wide range of specifications for packaging containers of daily chemical products. From 200ml to 5000ml, our machine efficiently produces shampoo, shower gel, dishwashing liquid, and other personal care products.
With our extensive manufacturing experience, we guarantee top-notch quality and excellent performance. Our machine supports multi-die head co-extrusion, ensuring high productivity to meet the demands of our customers.
Not only do our products boast exquisite craftsmanship, but they also offer exceptional versatility.
